Processorproducent

Intel

Processorserie

Intel® Xeon Silver

Processorgeneration

Intel Xeon Scalable 5th Gen

Processormodel

4510

Processorfrekvens

2,4 GHz

Processor boost frekvens

4,1 GHz

Processorkerner

12

Processor-cache

30 MB

Antal installerede processorer

1

Processor cache type

L3

Intern hukommelse

64 GB

Intern hukommelsestype

DDR5-SDRAM

Hukommelsesstik

16x DIMM

Hukommelsesur hastighed

5600 MHz

Hukommelseslayout (slots x størrelse)

2 x 32 GB

Maksimal intern hukommelse

1,5 TB

Understøttede SSD-størrelser

2.5"

Antal understøttede SSD'er

8

Understøtter RAID

Ja

Understøttede RAID-kontroller

HPE NS204i-u Gen11 NVMe Hot Plug Boot Optimized Storage Device HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller

Optisk drevtype

Ingen

On-board grafikkort

Ingen

On-board grafikkort, model

Ikke tilgængelig

Ethernet LAN

Ja

Ethernet-grænsefladetype

Gigabit Ethernet

Ethernet LAN-porte (RJ-45)

2

Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte

3

Udvidelsesporte

2 to 4 x16 PCIe Gen5 and 1 x16 OCP3 slot. Refer to the QuickSpecs for more detail.

Antal VGA-porte (D-sub)

1

Antal DisplayPorts

1

Antal administrationsporte

1 stk

Kabinettype

Tårn (4,5U)

Produktfarve

Sort

Administrationsplatform

Included: HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download) Optional: HPE iLO Advanced, HPE OneView Advanced (require licenses) and HPE Compute Ops Management. Refer to the iLO 6 User Guide

Trusted Platform Module (TPM)

Ja

Trusted Platform Module (TPM) version

2.0

Operativsystem installeret

Ingen

Strømforsyningstype

2x HPE 1000W Flex Slot Titanium Hot Plug Power Supply Kit

Strømforsyning

1000 W

Antal af hovedstrømforsyninger

2

Bredde

195 mm

Dybde

630 mm

Højde

600 mm

Vægt

12,3 kg

Standard ventilatorer

4x Standard Fans

Dimensioner (BxDxH) (efter britisk standard)

183,1 x 629,9 x 599,9 mm (7.21 x 24.8 x 23.6")

Lagerdisk type

None ship standard, 8 SFF supported

Sikkerhedsfunktioner

UEFI Secure Boot and Secure Start support. Intel Software Guard Extensions (SGX) support. Immutable Silicon Root of Trust. TPM (Trusted Platform Module) 2.0 support. Front bezel key-lock feature, Intrusion cable (Optional), Padlock slot and Kensington Lock slot support. For full security features refer to the QuickSpecs.

Vægt (efter britisk standard)

12,3 kg (27.1 Pund)

Antal understøttede processorer

1
