Passende til rumtype

Processor

Type

Alt-i-en væskekøler

Ventilator diameter

36 cm

Understøttede procesorsokler

LGA 1150 (stik H3), LGA 1151 (stik H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1700, LGA 2011 (Socket R), LGA 2066, LGA 775 (Socket T)

Omdrejningshastighed (min.)

900 rpm

Omdrejningshastighed (maks.)

1800 rpm

Blæser 2, diameter

12 cm

Blæser 2 omdrejningshastighed (min.)

900 rpm

Blæser 2 omdrejningshastighed (maks.)

1800 rpm

Understøttelse af puls-bredde modulering (PWM)

Ja

Pumpestik

3-stikben

Antal pr. pakke

1 stk

Kompatible produkter

Compatibilidad con Intel: LGA 775 / 1200 / 1151 / 1150 / 1155 / 1156 / 1366 / 1700 / 2011 / 2066 Compatibilidad con AMD: AM4 / AM5

Produktfarve

Sort

Materiale

Aluminium, Kobber

Antal blæsere

2 blæser(e)

Belysning LED

Ja

Belysningsfarve

Mono

LED-stiktype

3-stikben

Ventilatorstik

3-stikben

Certificering

This symbol indicates that electrical appliances should not be discarded with other household waste. Used equipment sho- uld be handed over to a local collection point for this type of waste or to a recycling center. Please contact your local authorities for information about disposal methods available in your area. Wa- ste electrical equipment may contain hazardous substances (e.g. mercury, lead, cadmium, chromium, phthaltes) which can get into air, soil and groundwater when leaking from used appliances. Environmental pollution with these substances leads to their bio- accumulation, causing lesion of disease in living organisms, which would pose a risk to human and animal health or life. Households may contribute to environmental protecion by proper waste collection. In such way, hazardous substances from the equipment are neutralized and valuable secondary raw materials are reused for production of new equipment.

Bredde

205 mm

Dybde

150 mm

Højde

450 mm

Vægt

1,53 kg

Pakkevægt

1,97 kg

Tekniske funktioner

Technical specification: • TDP: 300 W • Cooling standard: 360 mm • Radiator dimensions: 397 × 120 × 27 mm • Cooling pipes length: 460 mm • Heat sink material: Aluminium • Water block base material: Copper • Number of fans: 3 × 120 mm • Fan power connector: 4-pin (PWM) (male + female) • Fan LED connector: 3-pin (male + female) • Pump power connectors: 3-pin • Pump LED connector: 3-pin (male + female) • Fan speed: 900 - 1800 RPM • Pump speed: 2250 - 2750 RPM • Intel compatibility: LGA 775 / 1200 / 1151 /1150 / 1155 / 1156 / 1366 / 1700 / 2011 / 2066 • AMD compatibility: AM4 / AM5 • Set contents: Radiator with pump, 3 × 120 mm fans, mounting accessories, thermal paste, user manual

Garantiperiode

2 År

Sikkerhedsadvarsel

Safety conditions for heat sink and fan • Use the product in accordance with its intended use, as im- proper use may damage the product. • Do not expose the device to moisture. • The device should be cleaned only with a dry cloth. • Independent repairs and modification result automatic loss of the warranty. • Hitting or dropping may damage the product.

Overholdelse af affald af elektrisk og elektronisk udstyr (WEEE)

Ja

Tilgængeligt produkt- eller artikelinformationsark?

Ja

Monteringssæt

Ja

Skruer inkluderet

Ja

Antal skruer

24

Termisk pude inkluderet

Ingen

Fjernbetjening inkluderet

Ingen

Brugervejledning

Ja

Batterier inkluderet

Ingen

Installationsvejledning

Ja

Termisk fedt

Ja

Oprindelsesland

Kina
