Passende til rumtype

Computerkabinet

Type

Væskekølingssæt

Ventilator diameter

12 cm

Understøttede procesorsokler

LGA 1150 (stik H3), LGA 1151 (stik H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 1700, LGA 2011 (Socket R), LGA 2066, LGA 775 (Socket T)

Kompatibel processor serie

Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9

Omdrejningshastighed (min.)

900 rpm

Omdrejningshastighed (maks.)

2750 rpm

Understøttelse af puls-bredde modulering (PWM)

Ja

Pumpestik

3-stikben

Antal pr. pakke

1 stk

Pumpemotor hastighed (min.)

2250 rpm

Pumpemotor hastighed (maks.)

2750 rpm

Blæser, hastighed (min.)

900 rpm

Blæser, hastighed (maks.)

1800 rpm

Kompatible produkter

Compatibilidad con Intel: LGA 775 / 1200 / 1151 / 1150 / 1155 / 1156 / 1366 / 1700 / 2011 / 2066 Compatibilidad con AMD: AM4 / AM5

Produktfarve

Sort

Materiale

Aluminium

Køler materiale

Aluminium

Materiale for grundplade

Kobber

Antal blæsere

2 blæser(e)

Belysning LED

Ja

Belysningsfarve

Flere

LED-stiktype

3-stikben

Ventilatorstik

4-polet

Vandblokerende materiale

Kobber

Certificering

This symbol indicates that electrical appliances should not be discarded with other household waste. Used equipment sho- uld be handed over to a local collection point for this type of waste or to a recycling center. Please contact your local authorities for information about disposal methods available in your area. Wa- ste electrical equipment may contain hazardous substances (e.g. mercury, lead, cadmium, chromium, phthaltes) which can get into air, soil and groundwater when leaking from used appliances. Environmental pollution with these substances leads to their bio- accumulation, causing lesion of disease in living organisms, which would pose a risk to human and animal health or life. Households may contribute to environmental protecion by proper waste collection. In such way, hazardous substances from the equipment are neutralized and valuable secondary raw materials are reused for production of new equipment.

Antal SATA stik

1

Thermal Design Power (TDP)

250 W

Bredde

205 mm

Rørlængde

40 cm

Pumpe bredde

15 cm

Højde

450 mm

Vægt

1,53 kg

Pakkebredde

20 mm

Pakkedybde

15 mm

Pakkehøjde

35 mm

Pakkevægt

1,97 kg

Tekniske funktioner

Technical specification: • TDP: 250 W • Cooling standard: 240 mm • Radiator dimensions: 277 × 120 × 27 mm • Cooling pipes length: 400 mm • Heat sink material: Aluminium • Water block base material: Copper • Number of fans: 2 × 120 mm • Fan power connector: 4-pin (PWM) (male + female) • Fan LED connector: 3-pin (male + female) • Pump power connectors: 3-pin • Pump LED connector: 3-pin (male + female) • Fan speed: 900 - 1800 RPM • Pump speed: 2250 - 2750 RPM • Intel compatibility: LGA 775 / 1200 / 1151 / 1150 / 1155 / 1156 / 1366 / 1700 / 2011 / 2066 • AMD compatibility: AM4 / AM5 • Set contents: Radiator with pump, 2 × 120 mm fans, mounting accessories, thermal paste, user manual

Garantiperiode

2 År

Compliance-certifikater

CE

Sikkerhedsadvarsel

Safety conditions for heat sink and fan • Use the product in accordance with its intended use, as im- proper use may damage the product. • Do not expose the device to moisture. • The device should be cleaned only with a dry cloth. • Independent repairs and modification result automatic loss of the warranty. • Hitting or dropping may damage the product.

Overholdelse af affald af elektrisk og elektronisk udstyr (WEEE)

Ja

Tilgængeligt produkt- eller artikelinformationsark?

Ja

Kabler inkluderet

3-stikben, 4-polet, SATA

Monteringssæt

Ja

Skruer inkluderet

Ja

Antal skruer

16

Termisk pude inkluderet

Ingen

Fjernbetjening inkluderet

Ingen

RGB-controller inkluderet

Ja

Brugervejledning

Ja

Installationsvejledning

Ja

Adapterramme inkluderet

Ja

Oprindelsesland

Kina
