Name: Eaton PXL-C25/3 kredsløbsafbryder Miniature strømafbryder
SKU: 4015082364281
Price: 544 DKK
Availability: InStock

Eaton PXL-C25/3. Nominel strøm: 25 A, Nominel spænding: 400 V. Strømbryder type: Miniature strømafbryder, Kapacitet ved nedbrud: 10000 A, Kode for international beskyttelse (IP): IP20. Dybde: 70,5 mm<br>

Strømstyring

The maximum amount of electric current the device is designed to carry continuously under specified conditions, measured in amperes.

Nominel strøm

The specified electrical potential difference at which the device is designed to operate, measured in volts.

Nominel spænding

Funktioner

The specific design and functional category of the protection device, such as a Miniature circuit breaker or a Residual-current device.

Strømbryder type

The maximum fault current that the device can safely interrupt without sustaining permanent damage, measured in A.

Kapacitet ved nedbrud

The number of electrical poles or phases the device is designed to connect or switch (e.g., 1P, 3P).

Antal poler

The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".

Kode for international beskyttelse (IP)

The level of contamination of the environment in which the device is used, categorized by the risk of electrical breakdown due to pollution (e.g. 2 or 3).

Forureningsgrad

Driftsbetingelser

The minimum and maximum temperatures at which the product can be safely operated.

Eaton PXL-C25/3 kredsløbsafbryder Miniature strømafbryder

544 kr.

544 kr.

Produktbeskrivelse

Eaton PXL-C25/3 kredsløbsafbryder Miniature strømafbryder

544 kr.

544 kr.

Strømstyring
Nominel strøm	25 A
Nominel spænding	400 V

Funktioner
Strømbryder type	Miniature strømafbryder
Kapacitet ved nedbrud	10000 A
Antal poler	3
Kode for international beskyttelse (IP)	IP20
Forureningsgrad	2

Driftsbetingelser
Driftstemperatur (T-T)	-25 - 55 °C

Vægt & størrelser
Dybde	70,5 mm
