Name: Eaton NZMN2-A250 kredsløbsafbryder 3
SKU: 4015082590949
Price: 7455 DKK
Availability: InStock

Eaton NZMN2-A250. Nominel strøm: 250 A, Nominel spænding: 690 V. Kapacitet ved nedbrud: 85000 A, Kode for international beskyttelse (IP): IP20, Produktfarve: Sort, Hvid. Bredde: 105 mm, Dybde: 149 mm, Vægt: 2,35 kg<br>

color

weight

Strømstyring

The maximum amount of electric current the device is designed to carry continuously under specified conditions, measured in amperes.

Nominel strøm

The specified electrical potential difference at which the device is designed to operate, measured in volts.

Nominel spænding

Funktioner

The maximum fault current that the device can safely interrupt without sustaining permanent damage, measured in A.

Kapacitet ved nedbrud

The number of electrical poles or phases the device is designed to connect or switch (e.g., 1P, 3P).

Antal poler

The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".

Kode for international beskyttelse (IP)

The level of contamination of the environment in which the device is used, categorized by the risk of electrical breakdown due to pollution (e.g. 2 or 3).

Forureningsgrad

The colour e.g. red, blue, green, black, white.

Produktfarve

Specifies the official standards, safety approvals, or regulatory certifications the product has received.

Certificering

Driftsbetingelser

The minimum and maximum temperatures at which the product can be safely operated.

Driftstemperatur (T-T)

The minimum and maximum temperatures at which the product can be safely stored.

Opbevaringstemperatur (T-T)

Vægt & størrelser

The measurement or extent of something from side to side.

Bredde

The distance from the front to the back of something.

Dybde

Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

Eaton NZMN2-A250 kredsløbsafbryder 3

7.455 kr.

7.455 kr.

Produktbeskrivelse

Eaton NZMN2-A250 kredsløbsafbryder 3

7.455 kr.

7.455 kr.

Strømstyring
Nominel strøm	250 A
Nominel spænding	690 V

Funktioner
Kapacitet ved nedbrud	85000 A
Antal poler	3
Kode for international beskyttelse (IP)	IP20
Forureningsgrad	3
Produktfarve	Sort, Hvid
Certificering	IEC/EN 60947

Driftsbetingelser
Driftstemperatur (T-T)	-25 - 70 °C
Opbevaringstemperatur (T-T)	-40 - 70 °C

Vægt & størrelser
Bredde	105 mm
Dybde	149 mm
Vægt	2,35 kg
