Name: ABB S401M-B16 kredsløbsafbryder Miniature strømafbryder 1
SKU: 7612270101252
Price: 408 DKK
Availability: OutOfStock

ABB S401M-B16. Nominel strøm: 16 A, Indgangsfrekvens: 50/60 Hz, Nominel spænding: 400 V. Strømbryder type: Miniature strømafbryder, Smeltekurvetype: Type B, Kapacitet ved nedbrud: 10000 A. Bredde: 18 mm, Dybde: 82 mm, Højde: 91 mm. Antal pr. pakke: 1 stk<br>

color

weight

Strømstyring

The frequency (Hz) which is required to power the product.

Indgangsfrekvens

Nominel strøm

Nominel spænding

Totalt strømtab

Funktioner

Strømbryder type

Smeltekurvetype

Kapacitet ved nedbrud

Antal poler

The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".

Kode for international beskyttelse (IP)

Forureningsgrad

Energibegrænsende klasse

The way in which the product is being installed.

Installationstype

Beskyttelsesklasse

The colour e.g. red, blue, green, black, white.

Produktfarve

Driftsbetingelser

The minimum and maximum temperatures at which the product can be safely operated.

Driftstemperatur (T-T)

Vægt & størrelser

The measurement or extent of something from side to side.

Bredde

The distance from the front to the back of something.

Dybde

Height of the product, expressed in centimeters

Højde

Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.

Green Friday fejrer 10 år

ABB S401M-B16 kredsløbsafbryder Miniature strømafbryder 1

408 kr.

408 kr.

Produktbeskrivelse

ABB S401M-B16 kredsløbsafbryder Miniature strømafbryder 1

408 kr.

408 kr.

Strømstyring
Indgangsfrekvens	50/60 Hz
Nominel strøm	16 A
Nominel spænding	400 V
Totalt strømtab	2,2 W

Funktioner
Strømbryder type	Miniature strømafbryder
Smeltekurvetype	Type B
Kapacitet ved nedbrud	10000 A
Antal poler	1
Kode for international beskyttelse (IP)	IP20
Forureningsgrad	3
Energibegrænsende klasse	3
Installationstype	DIN-skinne
Beskyttelsesklasse	III
Produktfarve	Hvid

Driftsbetingelser
Driftstemperatur (T-T)	-25 - 60 °C

Vægt & størrelser
Bredde	18 mm
Dybde	82 mm
Højde	91 mm
Vægt	110 g

Emballeringsdata
Antal pr. pakke	1 stk
